เครื่องวัดความเรียบพื้นผิว > เครื่องวัดความเรียบผิว > Surface Roughness Tester รุ่น SRT-6200
Surface Roughness Tester with 2 Parameters (Ra, Rz)
SRT-6200 : Surface Roughness Tester รุ่น SRT-6200 ยี่ห้อ JEDTO
Surface Roughness Tester is design to measure 2 parameters (Ra, Rz) using the built-in Diamond pin probe. It has 4 wave filtering methods (RC, PC-RC,GAUSS & D-P). In addition, said parameters can be downloaded directly to PC via the optional RS-232 CD software & cables.This terster is widely used in production site to measure surface roughness of various machinery-processed parts and calculate corresponding parameters.
Easy measurement can be done by placing the sensor on the surface then uniformly slides along the surface by driving the mechanism inside the tester. The sensor measures the roughness of the surface via the sharp built-in probe.
This roughness causes displacement of the probe which results in change of inductive amount of induction coils so as to generate analogue signal, which is in proportion to the surface roughness at output end of phase-sensitive rectifier. The exclusive DSP processes and calculates then outputs the results clearly on LCD.
Easy measurement can be done by placing the sensor on the surface then uniformly slides along the surface by driving the mechanism inside the tester. The sensor measures the roughness of the surface via the sharp built-in probe.
This roughness causes displacement of the probe which results in change of inductive amount of induction coils so as to generate analogue signal, which is in proportion to the surface roughness at output end of phase-sensitive rectifier. The exclusive DSP processes and calculates then outputs the results clearly on LCD.
Special Features:
- Multiple parameter measurement: Ra, Rz
- Highly sophisticated inductance sensor
- Fourwave filtering methods : RC, PC-RC, GAUSS and D-P
- Built-inlithium ion rechargeable battery and controlcircuit with high capacity
- Selectable Metric (µm) and Imperial (µinch)
- ExclusiveDSP processes to output measurement results on LCD
- Rechargeable battery via USB cable or Power Adapter
Specifications:
| Multiple parameter measurement | Ra, Rz |
| Filtering methods | RC, PC-RC, GAUSS and D-P |
| Measuring Range | Ra: 0.05-10.00 µm / 1.000-400.0 µinch Rz: 0.020-100.0 µm / 0.780-4000 µinch |
| Accuracy | ≤10% |
| Repeatability | ≤ 6% |
| Fluctuation of display value | ≤ 6% |
| Sensor | ¤ Test Principle: Inductance type ¤ Material of Probe Pin: Diamond ¤ Radius of Probe Pin: 10µm ¤ Dynamo-measurement of Probe: 16mN(1.6gf) ¤ Vertical Radius of Guiding Head: 48mm ¤ Probe Angle: 90° |
| Maximum driving stroke | 17.5mm / 0.7inch |
| Cutoff Length | 0.25mm / 0.8mm / 2.5mm optional |
| Evaluation length | 1-5 cut-off optional |
| Driving speed | ¤ sampling length = 0.25mm Vt=0.135mm/s ¤ sampling length = 0.8mm Vt=0.5mm/s ¤ sampling length = 2.5mm Vt=1mm/s ¤ returning Vt=1mm/s |
| Resolution | ¤ 0.001µm if reading <10µm ¤ 0.01µm if 10µm =reading <100µm ¤ 0.1µm if reading =100µm |
| Data output | communicate with PC through RS232C interface (optional, not included in set) |
| Store memory | 7 groups of measurement |
| Display | 4 digits, 10mm LCD with blue backlight |
| Power | Li-ion battery, rechargeable |
| Operating conditions | ¤ Temperature: 0~50°C ¤ Humidity: <85% |
| Size | 140 x 57 x 48mm (5.5 x 2.2 x 1.9 inch) |
| Weight | about 420g |
Accessories:
¤ 1 x Digital Surface Roughness Tester
¤ 1 x Metal Carrying Case
¤ 1 x Standard Sensor
¤ 1 x Standard Sample Plate
¤ 1 x Operation Manual
¤ 1 x Screwdriver
¤ 1 x AdjustableLeg
¤ 1 x Sheathof Sensor
¤ Power Adapter (choose 1 from these available Adapter forUS, UK, Australia and Europe system)
¤ 1 x Metal Carrying Case
¤ 1 x Standard Sensor
¤ 1 x Standard Sample Plate
¤ 1 x Operation Manual
¤ 1 x Screwdriver
¤ 1 x AdjustableLeg
¤ 1 x Sheathof Sensor
¤ Power Adapter (choose 1 from these available Adapter forUS, UK, Australia and Europe system)
Optional:
หมายเหตุ ::
• ราคาสินค้ารวม ยังไม่รวมภาษีมูลค่าเพิ่ม 7%
• ราคาสินค้าไม่รวมค่าขนส่ง
• สเปคและราคาสินค้าอาจมีการเปลี่ยนแปลงโดยไม่แจ้งให้ทราบล่วงหน้า
Download Brochure ดาวโหลดโบร์ชัวร์สินค้า
SRT-6200 Brochure ( 0kb )
